K1 Calibration Block

EN12223 Standard

Large angle beam calibration block, 100 mm radius

Calibrate range with an angle beam transducer

Measure beam index point and refracted angle

For calibrating ultrasonic flaw detection equipment in both laboratory and on-site conditions. Our version of this block includes a 100mm radius, 3.0mm and 50.0mm holes, engraved reference mark scales, and two optional slots at the zero point which provide calibrating signals at intervals of 100mm range. In accordance with EN 12223 and ISO 2400.

This block is not to be confused with the older style "V1" Block, which is similar but V1 contains a 1.5mm through-hole rather than a 3.0mm hole.

• Dimensions: 300mm x 100mm x 25mm
